CMS is acronym of central monitoring station or central monitoring software. CMS software provides a centralized monitoring solution, allowing users to manage all video surveillance devices from one computer. Today our editor highly recommends you a most popular CMS software which offers robust functions, while have a great compatibility.
Lorex Client 11 is a client software for PC that allows you to connect to an ECO DVR in one of the Series listed above on a PC and view your cameras from anywhere in the world. Lorex Client 11 is a free download from the downloads tab for your DVR series. This video demonstrate how to setup CMS for H.264 camera DVR. This CMS works with many brands of DVR, but not all anyways. Download link: https://www.mediafi.
#1 Download 64CH DVR/NVR/IPC CMS SoftwareDownload Link
- Windows OS: https://goo.gl/UmXrDD (released on July, 2018)
- Mac OS: no software for Mac OS computers
License Free 64CH Video Surveillance Capability
This top rated software can support maximum 64 channel video management. Unlike those commercial VMS software, you don’t need to pay the license fee. You can use this software freely forever, there is no license registration is required.
H.264, H.265/HEVC video compression
The new CMS software has build-in H.264/AVI and H.265/HEVC decode algorithm can support both conventional H.264 and the latest H.265 video streams. No matter you’re using H.264 DVR or H.265 NVR, it can display the video and let you manage. We are so proud to claim this is the first CMS software can support H.265 DVR products in the world.
Unlike VMS software, this CMS is compatible with both digital and analog video surveillance devices. It can work with your DVRs/NVRs/IP Cameras. The supporting devices including H.264 DVR, AHD/TVI/CVI DVRs, H.265 DVRs, NVRs, IP Cameras. Most importantly, the software can accept video signals from cross different devices at a time. For instance, you can use the CMS to manage both AHD/TVI DVRs and IP Cameras.
Cms Dvr Viewer Software
The CMS software has embedded with different protocols to work with devices from diversity brands such as HIkvision, Dahua, XM, or any ONVIF compliant products from other manufacturers in the world. For instance, Hikvision iVMS4200/4500 software can not support third-party’s cameras, so many users can not use this software to manage Hikvision cameras and Dahua cameras simultaneously from the same PC. Now using this CMS software you can achieve video monitoring for cameras/DVRs from Hikvision, Dahua, XM, or other manufacturers like BOSCH, Vivotek, Honeywell, Yoosee.
Compatible with Windows XP/7/8/10 OS
The software is designed for working under all Windows OS PCs. It’s compatible with Windows XP, Windows 7, Windows 8, Windows 10 (32/64bit) OS. Installation and operating the software doesn’t require extra external library or extension. After complete installation, you’re able to choose software UI language. The software can support Arabic, Brazilian, Bulgarian, Czech, English, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Poland, Portugal, Romanian, Russian, Simple-Chinese, Spanish, Suomi, Thai, Traditional-Chinese, Turkish languages.
#2 How to install/use this software?
Login the software with default 'Super' user, no need to input password. After logon, you are able to modify account and assign permission. The next, the software will allow you to select software UI language, please choose your preferred language. The next, you need to add devices to the CMS.
Dvr Cms Client
On the right bottom of CMS software, you can find main menu, click main menu will reveal sub-menu items. Click 'PTZ' will reveal PTZ control buttons, and Preset function buttons. Click 'Color' will reveal video image parameter settings, you can change image brightness, contrast, saturation, white balance. Click 'System' will reveal system config menu including 'Device Manager, Local Config, Remote Config, Account, Local Log'. To add devices to CMS, we need to click 'Device Manager' from its sub-menu list.
The next, software will pop-up device manager window, select area where we need to add the device, then click 'add device'. It will pop-up 'Edit' window. Now we can search local devices then add them to the software. For DVRs, just hit 'IP Search' button to start to search the connected DVRs in local network. If you wish to add IP cameras or NVRs, you just need to tick 'Onvif Search' before click 'IP Search'. In addition to automatic searching, you can manually add devices as long as you know your device's IP address/domain, port number, as well as account information.
- IP Address: IPv4 address of your DVRs/NVRs/IPCs
- ARSP: using DVR's built-in DNS server to establish Internet connection. For example, you can input xmsecu.com to enable ARSP function.
- Domain: domain or DDNS of your devices
- Cloud: using CloudID to connect devices in WAN/Internet
- IPv6: IPv6 address of your video monitoring devices
- Vendor: H.264 DVR (Xiongmai DVR), Hikvision, Dahua, Huanghe, ONVIF
Vantage Dvr Cms Software Free
