Foison Vinyl Cutter Software

Description

The ultimate hobby and small decal machines for offices, schools, restaurants and stores, STIKA desktop cutters produce colorful POP displays,
labels, iron-ons and more. Creating custom vinyl graphics has never been faster or more affordable.

Project5 Photocut Processor is a bitmap tracer (raster to vector conversion program) that produces realistic photographic effect in Vinyl decals using Vinyl Cutter only. You can overcome Vinyl graphics limitations and produce any continuous tone image (photograph, landscape, etc.) with no additional costs. Easy Cut Studio Compatible Vinyl Cutters. We are always working hard on creating driver for your vinyl cutter (s) and we are proud to say that Easy Cut Studio is now supported with more than 680 vinyl cutters and cutting plotters. If you don't find your vinyl cutter in this list, contact our tech support to check if our software is compatible. Download vinyl cutter plotter software for free. System Utilities downloads - Roland STIKA DRIVER SV-12 by Roland DG Corporation and many more programs are available for instant and free download.

Small Roland, Big Features

For a compact product in its price range and class, the STIKA has a variety of big features that make it stand out. With bundled CutStudio software, users can tile up to 64 designs and contour cut printed images using an easy print registration function. It also features a simple USB connection and a sheet adjust lever for handling a wide range of media.

Available in 3 Sizes

STIKA SV-8
Accepts 8.5-inch wide media and cuts up to 6.2 inches wide.

Download

STIKA SV-12
Accepts 12-inch wide media and cuts up to 9.8 inches wide.

STIKA SV-15
Accepts 12 or 15-inch media and cuts up to 13.3 inches wide.

Easy and Fun to Use

Making professional-looking graphics is a snap with the STIKA. Simply design your graphics with bundled Roland CutStudio software, peel away the excess vinyl, and apply. It’s that easy. You can even contour cut printed graphics using your desktop printer and the STIKA driver. With a convenient USB port just like common desktop printers, the STIKA offers plug-and-play capabilities for both Mac and PC systems. USB included.

Use a Range of Masks and Materials

Vinyl
Twill
Paint mask
Heat transfer
Reflective vinyls
Etching material


CutStudio Software Included
Every STIKA comes with Roland CutStudio. This powerful design software lets you reduce, re-position, rotate, tile and mirror images. It enlarges images as crisp as original size and cuts TrueType fonts without outlining. CutStudio supports BMP, JPG, STX, AI, and EPS file formats. Plugins for Adobe Illustrator (Mac and PC) and Corel Draw (PC) are also included.

A Simple Print then Cut Solution
In addition to cutting vinyl and other materials, STIKA desktop cutters can be used as a simple and cost-effective solution for contour cutting printed graphics. Users print registration marks with their desktop printer, load the printed graphic into the STIKA, then send the file to the STIKA for contour cutting the graphics.

Foison Vinyl Cutter Software Free


Reliability and Warranty
Roland DG cutters have a worldwide reputation for outstanding quality and reliable performance. STIKA desktop cutters are backed by our first-rate customer service and a One-Year Trouble-Free Warranty.
Roland DG’s international ISO certification is further proof of our commitment to excellence.

Specifications

Foison Vinyl Cutter Software

MODELSV-15SV-12SV-8
Cutting methodMedia-moving method
Maximum cutting area13-3/8 (X) x 39-5/16” (Y)
[340 (X) x 1000mm (Y)]
9-13/16 (X) x 39-5/16” (Y)
[250 (X) x 1000mm (Y)]
6-1/4 (X) x 39-5/16” (Y)
[160 (X) x 1000mm (Y)]
Acceptable sheet size*Width: 14-1/8 to 15”
(360 to 381 mm)
Length: 43-1/4” (1100mm) or less
Width: 11 to 12”
(280 to 305mm)
Length: 43-1/4” (1100mm) or less
Width: 7-13/16 to 8-7/16”
(200 to 215mm)
Length: 43-1/4” (1100mm) or less
Cutting speed7/16 to 3-7/8ips.
(12 to 100 mm/sec.)
7/16 to 1-9/16ips
(12 to 40 mm/sec.)
7/16 to 1-9/16ips
(12 to 40 mm/sec.)
Acceptable materialPVC or label material of 0.004” (0.1 mm) or less in thickness. Total material thickness including the backing of 0.012” (0.3 mm) or less
Interface**>USB 1.1
Power supplyDedicated AC adapter input: AC 100V +/- 10%, 50/60Hz 1.7A Output: DC 19 V 2.1 A
External dimensions20-5/8(W) x 8-1/8(D) x 4-1/2”(H)
[522(W) x 205(D) x 115(H)mm]
17-3/8(W) x 8-1/8(D) x 4-1/2”(H)
[440(W) x 205(D) x 115(H)mm]
13-3/8(W) x 8-1/8(D) x 4-1/2”(H)
[340(W) x 205(D) x 115(H)mm]
Power consumptionAprox. 20W (including AC adapter)
Weight (unit only)7.3 lb [3.3 kg]6 lb. [2.7 kg]4.9 lb. [2.2kg]<
Acoustic noise level60 dB (A) or less (According to ISO 7779)
Operating environmentTemperature: 41 to 104 °F [5 to 40 °C]Humidity: 35 to 80% non-condensing
Included itemsAC adapter, power cord, USB cable, replaceable blade protector, blade, blade holder, pin, material for test cuts, application tape for test cuts, Roland Software Package CD-ROM (CutStudio design software, plug-ins for CorelDraw 10, 11,12 and Adobe Illustrator 9, 10, CS, Stika Windows Navi utility), SV-15/12/8 user’s manual

Foison Vinyl Cutter Software

*Depending on the type of material, lengths longer than 19-5/8” [500mm] may shift during cutting.
**Compatible with Windows 98 SE/Me/2000/XP and Mac OS 9 or later.
